Traditional pistol optics have spent decades refining the same mechanical architecture. The XRAY5™ was built to replace it.
The XRAY5™ Advanced Red Dot Sight redefines what shooters should expect from a pistol optic. Built on an innovative solid-state architecture featuring a rigid 225-dot matrix with no moving parts to wear or drift, the XRAY5 delivers unmatched durability and repeatable precision under the harshest conditions.
The patented Zero Distortion Optic (ZDO™) system delivers the industry’s clearest pistol optic sight picture to date, while intuitive Digital Zero technology allows shooters to establish, save, and instantly recall multiple zero profiles through the XRAY5 App. Combined with LightFight™ adaptive illumination, intelligent Round Counter functionality, and a fully enclosed optical system, the XRAY5 introduces an entirely new level of capability without compromising reliability.
Designed, developed, tested, and assembled in the USA, the XRAY5 is more than an evolution of the pistol optic; it is a new foundation for what a red dot sight can be.
Precision Built. Precision Kept.
Key Features:
- Ruggedized Solid-State Construction with no moving parts
- Patented Zero Distortion Optic (ZDO™) System
- Digitally Zero with simple app-guided setup
- Store and instantly recall multiple zero profiles
- LightFight™ adaptive reticle illumination
- Round Counter with reset function
- Fully enclosed, argon-purged optical system
- 7075 Aluminum housing with Grade 5 Titanium lens shield
- Side-loading CR2032 battery with 10,000-hour runtime
- MOTAC™ Motion Activated Illumination
- Designed, developed, tested, and assembled in the USA
- Fully backed by SIG SAUER’s Infinite Guarantee™
Available Accessories
Specifications
| SKU | SOX53300 |
|---|---|
| RX Footprint | PRO |
| Mount Type | Top Mount |
| Height | 1.17 in [29.72 mm] |
| Clear Aperture Diameter (Measured Diagonally) | 24 mm |
| Overall Length | 1.9 in [48.26 mm] |
| Overall Width | 1.32 in [33.53 mm] |
| Illumination Settings | 15[13 Day/2 NV] |
| Total Elevation Travel | 80 MOA |
| Total Windage Travel | 80 MOA |
| Run Time | Up to 10000 hours |
| Waterproofing | IPX-8 Up to 40 meters [132 ft] |
| Color | Black Anodized |
| Adjustment Method | Digital [Button presses / XRAY5 App ] |
| Battery | (1) CR2032 |
| Reticle | Red 3.5 MOA Dot |
Infinite Guarantee
SIG SAUER Electro-Optics are guaranteed forever. It's an unlimited lifetime guarantee.
ALT™
Precision molded aspheric lens technology virtually eliminates aberration, reduces weight, and helps to focus the projected image through the lenses for superior low distortion optical performance.
LensArmor™
Abrasion-resistant lens coatings for extreme durability ensure the lenses on your scope will stay sharp, bright, and clear.
SpectraCoat™
Highly efficient, ultra-wide broadband, anti-reflection lens coatings reduce surface reflections to extremely low levels across the entire visible spectrum providing superior light transmission.
D.A.R.C.
(Dark Adaptive Reticles & Coatings) Specialized lens coatings and reticle brightness settings that are optimized for use with GEN 3+ night vision devices
Bluetooth
Establish a wireless connection between your compatible SIG SAUER optic device and smartphones or Kestrels to maximize the functionality and capabilities of your optic. Manipulate device setting, load new ballistic profiles, and transfer data quickly and easily with the BDX 2.0 mobile app
Lightfight™
Digital Zero
Digital Round Counter
Zero Distortion Optical System
