The KILO6K-HDX Gen II Rangefinding Binocular delivers a wide variety of capabilities in a compact optical system designed for rugged environments. With a reengineered housing and armor, the KILO6K-HDX Gen II delivers the benefits of a larger 42mm objective lens while maintaining a slim, streamlined profile that won’t weigh you down. Upgraded with SIG SAUER’s HDX™ lens system to improve light transmission and optical resolution, the KILO6K-HDX Gen II features a redesigned rubber armor and updated textures around the main focus wheel and diopter adjustment rings for improved ergonomics.
Complete with SIG SAUER’s Archery Mode, Applied Ballistics Ultralight, and onboard environmental sensors, the KILO6K-HDX Gen II can connect with external devices from Kestrel and Garmin to deliver real-time environmental data and customized ballistic solutions. The KILO6K-HDX Gen II gives users the ability to create remote waypoints on ranged targets via onX Hunt and BaseMap mobile apps. The KILO6K-HDX Gen II features SIG SAUER’s powerful Gen II Lightwave DSP Ranging Engine, the same laser that has helped KILO series rangefinders dominate the hunting and long- range shooting space for a decade. Fully backed by SIG SAUER’s INFINITE GUARANTEE™.
FEATURES
- Less than one foot range resolution for short range accuracy
- Onboard temperature, pressure, and humidity sensors for accurate real-time ballistics calculations
- 5 target modes; first, best, last, fog, and extended range
- 5 range modes; applied ballistics, Ultralight (BDX-U), applied ballistics external (BDX-X), angled modified range (AMR), line of sight (LOS), archery (ARCH)
- Applied Ballistics Ultralight with complete AB bullet database, up to 25 custom ballistic profiles and 8 preset onboard ballistics groups
- BDX 2.0 enabled with low energy, long range Bluetooth
- Hyperscan provides 4 range updates per second in scan mode while Rangelock reports the last range results when ranging distant targets
*BDX units with Applied Ballistics Ultralite provide a firing solution out to a maximum of 800 meters.
Applied Ballistics External (BDX-X) allows the KILO to be paired with an external Kestrel Elite or
Garmin Foretrex for more precise ballistic solutions beyond 800m AB Elite includes support
for Coriolis, spin drift and other factors while providing custom drag curves for the most accurate
ballistic solutions in the industry
Specifications
| SKU | SOK6K106 |
|---|---|
| Model | KILO6K HDX |
| Color | ODG |
| Height | 2.3 in [ 58 mm ] |
| Magnification | 10x |
| Objective Lens Diameter | 42 mm |
| Overall Length | 5.24 in [ 133 mm ] |
| Overall Width | 5.3 in [ 135 mm ] |
| Battery | (1) CR2 |
| Display Type | Segmented OLED |
| Reticle | Circle |
| Weight | 24.7 oz [ 777 g ] |
| Eye Relief | 15.5 mm |
| Field of View | 6.3º |
| Diopter Adjustment Range | +/- 3 |
| Run Time | 4000 ranges |
| Range on Deer | Up to 2500 y |
| Range on Trees | Up to 3000 y |
| Max Reflective | Up to 6000 y |
| Laser Divergence | 1.6 x 0.1 MRAD |
LensArmor™
Abrasion-resistant lens coatings for extreme durability ensure the lenses on your scope will stay sharp, bright, and clear.
LightWave DSP™
Lightwave DSP (Digital Signal Processing) engine leverages HyperScan– an advanced power management technique that provides the fastest refresh rate in scan mode (4 times per second) even at distances over a mile. Our DSP engine uses the latest generation Field Programmable Gate Array (FPGA) running sophisticated signal processing algorithms to reduce false positives while finding weak or distant targets.
Lumatic™
The most advanced display on the market. Our OLED (Organic Light Emitting Diode) display has the largest dynamic range providing for high brightness in bright sunlight or snow conditions, yet will dim down to near nightvision levels at dusk and dawn. No other display offers this adaptive ability to prevent your pupil from constricting in low-light causing you to no longer be able to see your target.
SpectraCoat™
Highly efficient, ultra-wide broadband, anti-reflection lens coatings reduce surface reflections to extremely low levels across the entire visible spectrum providing superior light transmission.
Ballistic Data Exchange 2.0
Ballistic Data Exchange is a rangefinder and riflescope system that uses your ballistics, environmental conditions and Bluetooth to illuminate the exact holdover dot. BDX 2.0 is the Software Update that includes a new easy mode for quick BDX setup out of the box, including: BDX kits come paired and bonded. BDX Quickbond™ system gives users the ability to bond two BDX enabled devices without the smartphone app. BDX equipped KILO™ rangefinders preloaded with ballistic groups for centerfire rifles, muzzleloaders and crossbows. 100% compatible with BDX smartphone app to access the advanced BDX features in configuration options.
Angled Modified Range™
Angled Modified Range technology uses an onboard inclinometer that reads the incline/decline angle and modifies the effective ballistic shooting range to the target. AMR is the equivalent horizontal range and integrates perfectly when used in combination with SIG Ballistic Turret Dials.
Applied Ballistics
ONX
The OnX Hunt remote waypoint feature has been integrated into our BDX 2.0 App- KILO6K HDX RANGEFINDER OWNER'S MANUAL
