The new KILO6K-HD has a maximum reflective range of 6,000 yards and includes Applied Ballistics Ultralight onboard along with environmental sensors and supports BDX External (ABX) for connecting to external devices such as Kestrel and Garmin devices.
The KILO6K-HD features new target modes: Extended Range and Fog mode along with First, Best, and Last target. The rangefinder incorporates a segmented OLED display which provides range to target, elevation holdover and wind holds. All new KILO rangefinders connect with the BaseMap app to provide remote waypoints on ranged targets and can be fully configured with the SIG SAUER BDX App. All KILO K Series rangefinders leverage Low Energy / Long Range Bluetooth 5.x for multipoint Bluetooth connections and improved connectivity to BDX-enabled riflescopes and sights. The KILO6K-HD ships with a grey binocular harness.
FEATURES
- Onboard temperature, pressure, and humidity sensors for accurate real-time ballistic calculations
- 5 target modes; First, Best, Last, Fog, Extended Range
- 5 range modes; ABU, ABX, AMR, LOS, Archery
- BDX™ 2.0 enabled, providing your BDX riflescope with an automatically illuminated holdover dot through Bluetooth pairing
- Revolutionary LightWave DSP™ Technology for the fastest and longest distance range finder engine
- HyperScan™ Technology provides 4 range updates per second in scan mode while RangeLock™ reports the last range result when ranging distant targets
- Embedded Applied Ballistics Ultralight with bullet database and support for G1/G7
- Low Energy Bluetooth for synchronizing up to 25 custom ballistic profiles between the free SIG Ballistic App and rangefinder
- Advanced OLED display displays range and angle of incline as well as the ballistic solution
- Line of Sight or Angle Modified range in addition to full ballistic holdover and windage results in MIL or MOA
- Lumatic™ Display automatically calibrates display brightness to changing ambient light condition
- Compact, lightweight magnesium housing with binocular-style eyecup and diopter adjustment
- IPX-7 waterproof
- Free downloadable SIG BDX App for your smartphone, iOS, and Android are supported
- Drop remote waypoints with the Basemap app
- Covered by the SIG SAUER INFINITE Guarantee and Electronics Limited Warranty
*BDX units with Applied Ballistics Ultralite provide a firing solution out to a maximum of 800 meters.
Applied Ballistics External (BDX-X) allows the KILO to be paired with an external Kestrel Elite or
Garmin Foretrex for more precise ballistic solutions beyond 800m AB Elite includes support
for Coriolis, spin drift and other factors while providing custom drag curves for the most accurate
ballistic solutions in the industry
Specifications
| SKU | SOK6K105 |
|---|---|
| Model | KILO6K |
| Color | ODG |
| Height | 2.5 in |
| Magnification | 10x |
| Objective Lens Diameter | 42 mm |
| Overall Length | 5.7 in |
| Overall Width | 5 in |
| Battery | (1) CR2 |
| Display Type | Segmented OLED |
| Reticle | Circle |
| Eye Relief | 18 mm |
| Field of View | 6.1º |
| Diopter Adjustment Range | +/- 3 |
| Run Time | 4000 ranges |
| Range on Deer | Up to 2000 y |
| Range on Trees | Up to 4000 y |
| Max Reflective | Up to 6000 y |
| Laser Divergence | 1.5 x 0.6 MRAD |
Infinite Guarantee
SIG SAUER Electro-Optics are guaranteed forever. It's an unlimited lifetime guarantee.
LightWave DSP™
Lightwave DSP (Digital Signal Processing) engine leverages HyperScan– an advanced power management technique that provides the fastest refresh rate in scan mode (4 times per second) even at distances over a mile. Our DSP engine uses the latest generation Field Programmable Gate Array (FPGA) running sophisticated signal processing algorithms to reduce false positives while finding weak or distant targets.
Lumatic™
The most advanced display on the market. Our OLED (Organic Light Emitting Diode) display has the largest dynamic range providing for high brightness in bright sunlight or snow conditions, yet will dim down to near nightvision levels at dusk and dawn. No other display offers this adaptive ability to prevent your pupil from constricting in low-light causing you to no longer be able to see your target.
SpectraCoat™
Highly efficient, ultra-wide broadband, anti-reflection lens coatings reduce surface reflections to extremely low levels across the entire visible spectrum providing superior light transmission.
Ballistic Data Exchange 2.0
Ballistic Data Exchange is a rangefinder and riflescope system that uses your ballistics, environmental conditions and Bluetooth to illuminate the exact holdover dot. BDX 2.0 is the Software Update that includes a new easy mode for quick BDX setup out of the box, including: BDX kits come paired and bonded. BDX Quickbond™ system gives users the ability to bond two BDX enabled devices without the smartphone app. BDX equipped KILO™ rangefinders preloaded with ballistic groups for centerfire rifles, muzzleloaders and crossbows. 100% compatible with BDX smartphone app to access the advanced BDX features in configuration options.
Angled Modified Range™
Angled Modified Range technology uses an onboard inclinometer that reads the incline/decline angle and modifies the effective ballistic shooting range to the target. AMR is the equivalent horizontal range and integrates perfectly when used in combination with SIG Ballistic Turret Dials.
Applied Ballistics
